Case CX490D - Track Tension

6-MAINTENANCE
Tracktension
WARNING
Tip-overhazard!
Onlyraisethetrackaslittleasnecessary.
Failuretocomplycouldresultindeathorseriousinjury.
W0276A
Checkthetracktensionperiodically
NOTICE:ifthetracksaretootight,theywearquickly.Iftracksarenottightenough,theywearquicklyandthelinks
cancatchonthesprocketwheelorslideofftheidlerwheelorthesprocketwheel.Cleanthetracksafterwork.
Tocheckthetrackstension,proceedasfollows:
1.Swingtheupperstructuretoastraightanglerelative
totheundercarriage.Lowertheattachmenttothe
ground,thenlowertheboomuntilthetrackisraised
offtheground.Placeablockundertheundercar-
riageandraisetheattachmentofftheground.
SMIL15CEXY655AA1
2.Turntheenginespeedthrottletothemaximum
speedposition.
SMIL15CEXY892AB2
3.Pressthetravelmodeselectorbutton(1)tosetthe
"Rabbit"mode.
SMIL15CEX0224AA3
6-74
