Accesstooperator'splatform
Doorandsteps
CAUTION
Pinchhazard!
Becarefulnottogetyourhand,clothes,etc.caughtinthedoorwhenclosingit.
Failuretocomplycouldresultinminorormoderateinjury.
C0046A
Cabdoor
Toopenthedoor,usethehandle(1)fromtheoutsideand
usethehandle(2)fromtheinside.
NOTICE:Beforeopeningthedoorfromtheinside,make
suretoplacethegatelockleverincentralposition.The
left-handcontrollevermightbetouchedinadvertently
whenopeningthedoor,andthemachinemaythusmove
suddenlyandinadvertentlycausingsevereincidents.
SMIL14CEX1649AB1
SMIL14CEX1650AB2
Thedoorcanbelatchedincompletelyopenposition.
NOTICE:Neverworkleavingthedoorajar.Beforeper-
forminganyworkwiththedooropen,makesuretolockit
inthecompletelyopenposition.
Tounlatchthedoor,stopmachineoperation,setthegate
locklevertocentralposition,andtiltthelever(3)down-
ward.
SMIL14CEX1651AB3
