Case CX490D - Left-Hand Side Controls

3-CONTROLSANDINSTRUMENTS
Left-handsidecontrols
Left-handsidecontrols
SMIL15CEXY927EB1
(1)Armangleadjustmentlever:theleverenablesthe
controlarmtobeadjustedindifferentinclinesinaccor-
dancewiththeoperator'sbodyprole.Holdtheleverand
selectthedesiredposition,andthenreleasethelever.
NOTE:stoptheenginebeforeadjustingthecontrolarm.
(2)Gatelocklever.
(3)Safetybar.
(4)Hornbutton.
NOTICE:makesuretosoundthehornbeforestartingthe
engineandresumingmachineoperation.
(5)Storagetray.
(6)Notactive.
(7)Radiomutebutton:theradiomutebuttonislocated
underneaththecontrollever.Pushthebuttontomutethe
volume.Pushitagaintoresumethevolume.
(8)Controlofheating,ventilationorairconditioning.
(9)Emergencystopswitch(RefertoChapter4).
(10)Freeswingbutton:thebuttonsetstheconditionof
swingstop.Ifthefreeswingisactivatedtheswingstop
isdelayed.Pressthebuttontoactivatethefreeswing
function.Thefreeswingiconappearsonthemonitor.
Pressthebuttonagaintodeactivatethefunction.
Thefreeswingfunctionisintendedtobeusedespecially
forloadhandlingapplicationtoavoidloadsfromslinging.
Thefreeswingfunctionisautomaticallydisabledwhen
stoppingtheengine.
NOTICE:avoidworkingonaslopewiththefreeswing
functionactive.Theswingbecomeshardtostop.
NOTICE:whenparkingonaslope,neveractivatethefree
swingfunctionfromthemachineparkingposition.The
machinemaystarttoswingbecausetheswingparking
brakeisreleased.
(11)Fanreversingbutton(RefertoChapter4).
3-14
