6-MAINTENANCE
Fuseandrelaylocations
Fuses
Toreplaceafuseproceedasfollows:
1.TurnthestarterkeytoOFFposition.
2.Opentheprotectivecoverofthefuseboxlocatedbe-
hindtheoperator'sseat.
SMIL18CEX0782AA1
3.Identifythefusetobereplaced.Refertothefusemap
onthefollowingpage.
NOTE:Thefusemapisalsoreportedonlabelsappliedon
thefusebox.
NOTICE:Makesuretoreplacethefailedfusewithoneof
thesameamperage.Failingtocomplywillresultinserious
damagestotheelectricsystemofthemachine.
4.Openthefuseboxthatcontainsthefusetobereplaced.
5.Usetheprovidedjigstoremovethefailedfuse,andto
installthenewfuse.
6.Closethefuseboxandtheprotectivecover.
6-88
