6-MAINTENANCE
SMIL18CEX0784GB2
Fusefunctions
Fusebox(1)Fusebox(2)
(F1)Keyswitch10A(F1)Seatsuspensionheater10A
(F2)Accessory10A(F2)Wiperandwasher15A
(F3)ControllerGPS10A(F3)Cigarlighter10A
(F4)Monitor10A(F4)DCconverter10A
(F5)Controller10A(F5)FieldViewMonitor10A
(F6)Leverlock(gate)10A(F6)Spare110A
(F7)Airconditionerunit5A(F7)Beacon10A
(F8)Airconditionerblowermotor15A(F8)Lampcab15A
(F9)Airconditionercompressor5A(F9)Lampboom,house15A
(F10)Controllerengine20A(F10)Option10A
(F11)Monitor(backup)10A(F11)Spare210A
(F12)Backup10A(F12)Indicator10A
(F13)Solenoid15A
(F14)Proportionalsolenoid15A
(F15)Horn10A
NOTE:ifCASECONSTRUCTIONSiteWatch™Telematicssystemisequipped,adedicated5Afuseisaddedout-
sideofthemainfusebox.Thefuseconnectorislocatedunderneaththepanelsbehindtheoperator'sseat.
6-89
