Case CX490D - Swing Reduction Unit Oil

6-MAINTENANCE
Swingreductionunitoil
WARNING
Hotsurfacepossible!
Waitforallcomponentstocoolbeforeperforminganyoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0251A
Replacetheswingreductionunitoilevery1000h(After250hofoperationinrun-inperiod).
Lubricant:TUTELAHYPOIDEEPGEARLUBESAE80W-90.
Quantity:10.5L(2.8USgal).
1.Parkthemachineonaatandlevelplace.Stopthe
engine,andremovethestarterkey.
2.Removetheoilgauge(1)andthellplug(2).Clean
theoilgaugewithaneatcloth.
SMIL15CEXY508AB1
3.Removethelowerpanel(3).
SMIL19CEX1996AA2
4.Placeacontainerwithanappropriatecapacityunder
theupperstructureframe.Removetheoildrainplug
(4)todrainoil.
NOTE:Drainingoilrequiresacomparativelylongtime.
NOTE:Checktheconditionofthedrainedoil.Ifforeign
objects,suchasmetalscrapings,areincluded,consultthe
CASECONSTRUCTIONdealer.
