Case CX490D - Page 249

To Next Page

To Previous Page

6-MAINTENANCE

5.Attachthedrainplug(4),andinstallthelowerpanel(3).

6.Supplyoilviathellport(2).

7.Attachtheoilgauge(1)andcheckthattheoillevelis

inthehatchedarea.

8.Waitfor10minandchecktheoillevelagain.Ifneces-

sary,supplyadditionaloilviathellport(2).

9.Attachthellplug(2)

SMIL15CEXY508AB4

6-55
