3-CONTROLSANDINSTRUMENTS

Mirrors

SMIL15CEXY167EB1

(A)Leftmirror—(B)Right-frontmirror—(C)Right-centermirror

Installationandpositioningofthemirrors

WARNING

Avoidinjuryand/ormachinedamage!

Keepthemirrorscleanandproperlyadjusted.

Failuretocomplycouldresultindeathorseriousinjury.

W1078A

Theexternalmirrors,alongwiththeexternalcameras,en-

surepropervisibilityaroundthemachineduringoperation.

Thehatchedareasinthepicturesindicatethezonesthat

canbeviewedbyeachmirror.
