4-OPERATINGINSTRUCTIONS
Movingtheunit
Machinetravel
WARNING
Controlscanbereversed!
Inthenormaltravelposition,theoperator'scompartmentisabovetheidlerwheelsandthetravel
reductiongearsaretotherearoftheupperstructure.Iftheupperstructureisturned180degreesin
relationtotheundercarriage,thecontrolsarereversed.
Failuretocomplycouldresultindeathorseriousinjury.
W0289A
WARNING
Hazardtobystanders!
Alwayssoundthehornbeforestartingthemachine.Makesuretheworkareaisclearofotherpersons,
domesticanimals,tools,etc.beforeyouoperatethemachine.Neverallowanyoneintheworkarea
duringmachineoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0304A
NOTE:increasetheenginespeedbeforestarttraveling.
Foldtheattachmenttoraiseitto40–50cm(15.7–
19.7in)aboveground.
Selectionoftravelspeed
WARNING
Lossofcontrolhazard!
Avoidpressingthetravelspeedbuttonwhile
traveling.AvoidshiftingtoFASTspeedwhen
travelingdownhillorwhenloading/unloading
fromatrailer.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0390A
Beforestarttraveling,makesuretoselecttheproper
travelmodebetween"Turtle"and"Rabbit".
Asthetravelmodeisselected,thetravelspeedvaries
withthetiltingangleofthetravelcontrolleversandpedals.
RefertoChapter8forspeedranges.
SMIL15CEXY193AA1
Travelalarm
Thetravelalarmsoundsdependingonthepositionofthe
switchlocatedontherighthandconsole:
AUTOOFFposition:thealarmsoundsforonly10s
eachtimethetravelcontrolsareactivated.
CONTposition:thealarmsoundscontinuouslyeach
timethetravelcontrolsareactivated.
