3-CONTROLSANDINSTRUMENTS

Frontlowerwindow

Thefrontlowerwindowmayonlyberemovedwhenthe

windshieldisopen.

1.Removethewindowfromitshousingbyslidingitup-

ward.

SMIL14CEX1687AA1

2.Placethewindowinthestoragepositionprovidedto

theleftoftheoperator'sseatandthenengageitcor-

rectly.

SMIL14CEX1688AA2

3-13
