5-TRANSPORTOPERATIONS
Settingtheadjustableundercarriageintothetransportposition
WARNING
Hazardtobystanders!
ALWAYSmakesuretheworkareaisclearofbystandersanddomesticanimalsbeforestartingthis
procedure.Knowthefullareaofmovementofthemachine.Donotpermitanyonetoenterthearea
ofmovementduringthisprocedure.
Failuretocomplycouldresultindeathorseriousinjury.
W0245A
TheundercarriageoftheRTCversionhasastructurethatallowstoretractthesideframes.Theretractionoftheside
framesisintendedtoreducetheoveralltrackgaugeforroadtransport.
NOTICE:theRTCundercarriageshallbealwaysinextendedpositionfornormaleldoperation.Neveroperatewith
theRTCundercarriageinretractedposition.Intheretractedposition,theoverallmachinestabilityissignicantly
reduced.
Retractionofsideframes
1.Parkthemachineonahardandlevelsurfacecloseto
thetransporttrailer.
2.Removethe24xingbolts(1)fromtheretaininghard-
wareofthesideframetoberetracted.
NOTICE:neverremovethebolts(2)ofthesideframe
guides.
3.Swingtheupperframetothesideframetobere-
tracted.Upperframeandundercarriageshallbeat
90°.
W79XCS-0011
WARNING
Tip-overhazard!
Onlyraisethetrackaslittleasnecessary.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0276A
4.Positionthefrontequipmentasshowningure.Make
surethatthebottomsideofthebucketpushesona
hardground.
5.Usethefrontequipmentasalevertoslightlyraisethe
trackfromtheground.Thesideframeslidesbygravity
towardsthebaseframeoftheundercarriage.The
stoppersonthesideframeguidessettheretracted
position.
SMIL15CEXY210AB2
5-6
