5-TRANSPORTOPERATIONS
6.Ifthetrackdoesnotslide,insertablock(1)(about
50mm(2.0in)x50mm(2.0in)underthetrackon
theouterside.Slowlylowertheboomuntilthetrack
slowlyslidesuntilcomingtothestop.
7.Slowlylowerthetracktotheground.
SMIL15CEXY211AB3
8.Makesurethattheretaininghardwareonthebase
frameoftheundercarriagematchesthexingholes
onthesideframe.
9.Install12xingboltstotheretaininghardware.The
tighteningtorquemustbe1470–1920N·m(1084–
1416lbft).
10.Repeatsteps2to9fortheothertrack
11.Storethe24unusedboltsinthefrontstoragebox.
Themachineisnowreadyforbeingdisassembledintoits
mainmodules.
W79XCS-0044
ExtensionofSideFrames
1.Assemblethemainmodulestothebasemachine.
Parkthemachineonahardandlevelsurface.
2.Wraptwocables(C)aroundthefrontsectionandthe
rearsectionofthesideframetobeextendedasshown
ingure.Makesuretousepaddingstoavoiddam-
agestothesideframeandtothecables.
3.Connecttheendsofeachcabletoaratchetlever
winch(R).
SMIL15CEXZ412AB5
4.Removethe12xingbolts(1)fromtheretaininghard-
wareofthesideframetobeextended.
5.Swingtheupperframetothesideframetobeex-
tended.Upperframeandundercarriageshallbeat
90°.
W79XCS-0046
5-7
