Case CX490D - Display Operation and Machine Status

3-CONTROLSANDINSTRUMENTS
Instrumentcluster
(1)Ambientsensor
NOTE:Donotplaceanyobjectontheambientsensor:
theclimatecontrolsystemmaynotcorrectlycontrolthe
temperatureinsidethecab.
(2)Display
(3)Controlbuttons
(4)Airvents
NOTE:Theairventsshouldbemanuallyset.Makesure
tosettheopeningandthedirectionoftheairventsinorder
tograntthedesiredconditionintothecabenvironment.
NOTICE:Ifwatergetsinsidetheinstrumentcluster,itcan
beseriouslydamaged.Makesuretokeeptheinstrument
clusterprotectedfromwaterandfromanykindofuid.
Useonlyasoft,dryclothtocleantheinstrumentcluster.
SMIL14CEX1689BB1
