Travelreductionunitsoil
Checkthetravelreductiongearsoillevelevery250h.
Lubricant:TUTELAHYPOIDEEPGEARLUBESAE80W-90
1.Parkthemachineonat,horizontalground.
2.Movethemachinesothatthedrainplug(1)comes
downtothelowestposition.
3.Stoptheengineandremovethestarterkey.
4.Removethelevelplug(2),andchecktheoillevel.If
thelevelcomesuptothebottomedgeoftheport(2),
itissufcient.
Ifnecessary,addoilthroughtheport(2)untiltheoil
comesuptothebottomedgeoftheport(2).
5.ChecktheO-ringsealofthelevelplug(2)fordamages,
andreplaceitifnecessary.Insertthelevelplug(2)with
sealtapewrappedaroundit.
6.RepeatSteps2to5fortheothertravelreductiongear.
7.Runthemachineslowlytocheckthatthereareno
leaks.
SMIL15CEXY509AB1
