Case CX490D - Side Doors

3-CONTROLSANDINSTRUMENTS
Sidedoors
WARNING
Movingparts!
Makesureallentryandmechanicalaccessdoorsareproperlyclosedbeforeoperatingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0238A
Openthesidedoorsuntiltheyarexedbythestays.Closethesidedoorsunlockingthestays.Makesuretoclose
thedoorsrmly.Usethestarterkeytolockthedoors.
Rearright-handdoor
Therearright-handdoorallowstoaccessthecompart-
mentincludingtheengineoillters,thefuellters,the
hydraulicpilotlter,thehydraulicaccumulatorandthehy-
draulicpump.
NOTE:Neverleavetoolsinsidethecompartment.
SMIL15CEXY180AA1
Rearleft-handdoor
Therearleft-handdoorallowstoaccessthecompartment
includingtheradiators,theoilcoolerandtheaircondition-
ingdryer.
NOTE:Neverleavetoolsinsidethecompartment.
SMIL15CEXY181AA2
Frontleft-handdoor
Thefrontleft-handdoorallowstoaccessthecompartment
includingtheengineaircleaner,thereservetankforen-
ginecoolant,thebatteries,thebatterydisconnectswitch
andthewindshieldwashertank.
NOTE:Neverleavetoolsinsidethecompartment.
SMIL15CEXY182AA3
3-69
