3-CONTROLSANDINSTRUMENTS

Thecamerasystemhasarangewherenoimageis

displayed(blindspots):

(1)Rangewherenoimagefromtherearcameraisdis-

played.

(2)Rangewherenoimagefromtheright-sidecamera

isdisplayed.

SMIL15CEXY177BB9

SMIL15CEXY178BB10

3-68
