Case CX490D - Machine Dimensions and Operating Weights

8-SPECIFICATIONS
Dimensions
CX490DLC
SMIL20CEX1321FA1
Arm
2.53m(99.61in)3.38m(133.07in)4.00m(157.48in)4.85m(190.94in)
(A)3.67m(144.49in)3.65m(143.70in)3.63m(142.91in)4.42m(174.02in)
(B)12.11m(476.77in)12.09m(335.43in)12.07m(475.20in)12.18m(479.53in)
(C)3.72m(146.46in)
(D)(withoutgrousers)1.33m(52.36in)
(E)4.40m(173.23in)
(F)5.45m(214.57in)
(G)3.06m(120.47in)
(H)(*)3.32m(130.71in)
(I)3.55m(139.76in)
(J)3.55m(139.76in)
(K)(withoutgrousers)0.535m(21.06in)
(L)(standardtrack)0.90m(35.43in)
(M)2.75m(108.27in)
(N)750mm(30in)track3.50m(137.80in)
(N)900mm(35in)track3.65m(143.70in)
(O)Sidecatwalks(Optional)3.59m(141.34in)
(P)3.56m(140.16in)
Boomlength:6.98m(274.80in)
NOTE:(*)3.40m(133.86in)ifFOPSlevel2isinstalled.
NOTICE:The2.53m(99.61in)armisasuper-shorttypearm.Thedimension(A)andthedimension(B)ofthe
referencepositionshowningurearemeasuredwiththearmfullyclosedandthebucketnotfullycurled.Donotfully
curlthebucketinordernottohittheboom.
8-6
