Case CX490D - Fuel Tank Filler Pump (if Equipped)

3-CONTROLSANDINSTRUMENTS
Fueltankllerpump(ifequipped)
WARNING
Firehazard!
Whenhandlingdieselfuel,observethefollowingprecautions:
1.Donotsmoke.
2.Neverllthetankwhentheengineisrunning.
3.Wipeupspilledfuelimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0099A
NOTICE:Donotputamoistureeliminationproduct(waterdrainingagent)inthefueltank.Itmaydamagetheengine.
NOTICE:Thefueltankllerpumpislocatedinsidethestorageboxontherightfrontoftheupperstructure.Useonly
forsuitablefuel.
1.Parkthemachineonat,horizontalground,stopthe
engineandturnthestarterkeytoONposition.
2.Taketheinletpipeoutofthefrontstoragebox.
SMIL14CEX2514AA1
3.Measuretheheightofthedrumandplacetheidenti-
cationclamp(1)ofthesuctiontubeatalengthslightly
lessthanthatofthedrumheight.
4.Makesurethattheendstrainerofthesuctiontubeis
correctlyattachedandtheninsertthesuctiontubein
thedrum.
SMIL14CEX2515AB2
5.Removethefueltankllercap.
WARNING
Burnhazard!
Ifthellercapremainsonduringtherefuel-
ingprocess,removingthecapafterrefueling
couldcauseanaccident.Toreducethisrisk,
ALWAYSremovethefueltankllercapbefore
refuelingwiththefueltankllingpump.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0247A
SMIL15CEXY187AA3
3-76
