Case CX490D - Lower Panels; Windshield Washer Reservoir; Towing Holes

3-CONTROLSANDINSTRUMENTS
Lowerpanels
WARNING
Movingparts!
Makesurethelowerpanelsareproperly
closedbeforedrivingthemachine.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0910A
Locatedonthebottomsideoftheupperframe.Thelower
panelsgiveaccesstotheengineoildrainplug,tothe
hydraulictankdrainplug,tothefueltankdrainplug.
SMIL14CEX2588AA1
Windshieldwasherreservoir
Thewindshieldwasherreservoirislocatedinsideoneof
theleft-handcompartmentsbehindthecab.
Makesuretocheckthereservoirleveleachdayinorder
nottoletthewindshieldwashinguidrunoutcompletely.
NOTICE:Neveroperatethewindshieldwasherwhenthe
reservoirisempty.Thiswillcausedamagetotheelectric
pump.
NOTE:Incoldweather,addanti-freezetothewindshield
washinguid.
NOTE:Thereservoircanbeliftedoutofitssupportin
ordertoeasethemaintenanceoperations.
SMIL13CEX2650AB1
Towingholes
WARNING
Misusehazard!
Towingisadelicatemaneuverthatisalwayscarriedoutattheriskoftheuser.Themanufacturer's
warrantydoesnotapplytoincidentsoraccidentsthatoccurduringtowing.Wherepossible,carryout
therepairsatthesite.
Failuretocomplycouldresultindeathorseriousinjury.
W0286A
Locatedatthefrontandrearoftheundercarriage.
Theseholesareusedtotowheavyobjects,upto10t
(22046.23lb).
Makesurethattheslings,chainsandaccessoriesarein
perfectconditionandcanbeartheloadtobemoved.
NOTICE:Towingmustalwaysbedoneinalignmentwith
theundercarriage.
SMIL14CEX2589AA1
3-73
