3-CONTROLSANDINSTRUMENTS
Batterydisconnectswitch
WARNING
Electricalshockhazard!
Beforeyouworkonanypartoftheelectricalsystem,disconnectthebatterygroundcableorturnthe
batterydisconnectswitchoff(ifequipped).
Completeallelectricalworkbeforeyoureconnectthecable.
Failuretocomplycouldresultindeathorseriousinjury.
W1393A
Thebatterydisconnectswitchislocatednearthebatter-
ies.Itcanthusbereachedbyopeningthefrontleft-hand
door.
Thebatterydisconnectswitchallowstocutoffanypower
supplyintheelectricalsystemofthemachine.
NOTE:WhentheswitchisturnedtoOFFposition,the
stationsstoredontheradiopresetsandthetimesetfor
theclockwillbecleared.
SMIL15CEXZ407AB1
ThebatterydisconnectswitchshouldbeinONposition
fornormaloperation.
SMIL16CEX1757AA2
ThebatterydisconnectswitchshouldbeturnedtoOFF
positiononlywhentheactionsbelowmustbedone:
1.Serviceontheelectricalsystem.
2.Batteriesremoval.
3.Long-termstorage.
BeforeturningthebatterydisconnectswitchtoOFFposi-
tion,makesuretoparkthemachineandtostoptheen-
gine.
NOTICE:IfthebatterydisconnectswitchisturnedtoOFF
positionwhentheengineisrunning,themachineelectri-
calsystem,themachinecontrolsystemandtheengine
controlsystemwillbeseverelydamaged.
SMIL16CEX1758AA3
