Case CX490D - Counterweight and Vandalism Guard Systems

9-ACCESSORIES
Counterweightremovalsystem
WARNING
Hazardtobystanders!
ALWAYSmakesuretheworkareaisclearofbystandersanddomesticanimalsbeforestartingthis
procedure.Knowthefullareaofmovementofthemachine.Donotpermitanyonetoenterthearea
ofmovementduringthisprocedure.
Failuretocomplycouldresultindeathorseriousinjury.
W0245A
WARNING
Heavyobject!
Cleartheareaaroundandunderthecounterweightremovalandinstallationsystembeforeinstalling
orremovingcounterweights.Keepallunauthorizedpersonnelclearofthearea.Makesurealllifting
devicesareingoodconditionandcapableofhandlingthecounterweightmass.
Failuretocomplycouldresultindeathorseriousinjury.
W0037A
Localizationofthecontrolofcounterweightremovalsystem
Themachinecanbeequippedwithasystemthatallowsanautomatichandlingofthecounterweightinordertoremove
andinstallitwithoutneedofexternalliftingequipments.
Themaincontrolstooperatetheautomaticcounterweightremovalsystemarelocatedintherearright-handcompart-
ment.
SMIL20CEX1343EA1
1.Counterweightremovalcontroller
2.Stopvalve
NOTICE:Improperuseofthecounterweightremovalsystemcancauseseriousdamagetothemachineandtoanyone
nearthemachine.
9-49
