(1)Cigarettelighterand24Vpowersupplysocket:the
deviceisactivewiththestarterkeyinONposition,or
whiletheengineisrunning.
Tooperatethecigarettelighter,pushitdowntoengage
itsheatingposition.
NOTICE:keeppushingthecigarettelightercancausese-
riousdamagestothedeviceandtothemachineelectrical
system.
NOTICE:theelectricalsystemmaybedamagedifthe
cigarettelighterdoesnotreturntoitsoriginalpositionaf-
ter30s.PullitoutmanuallyandconsulttheCASECON-
STRUCTIONdealer.
NOTICE:connectonly24Vdevicestothesocket.Con-
nectingdevicesfunctioningatdifferentvoltagecancause
damagestothedeviceitselfandtotheelectricalsystem.
(2)Storagetray.
(3)Ashtray.
(4)Hornvolumeloweringswitch:thehornvolumelower-
ingswitchallowstochangethevolumeofthehorn.Press
theONsideoftheswitchtolowerthevolumeofthehorn.
PresstheOFFsideoftheswitchtoresumethenormal
volumeofthehorn.
(5)12Vpowersupplysocket:thedeviceisactivewiththe
starterkeyinONposition,orwhiletheengineisrunning.
NOTICE:connectonly12Vdevicestothesocket.Con-
nectingdevicesfunctioningatdifferentvoltagecancause
damagestothedeviceitselfandtotheelectricalsystem.
(6)Hydraulicquickcouplingsystemactivationswitch(op-
tional,refertoChapter9).
(7)Aroundlightingswitch(optional):thearoundlighting
switchallowstoactivatethearoundlightingsystemin-
stalledonthecameras.Pressthebacksideoftheswitch
toactivatethelighting.Pressthefrontsideoftheswitch
todeactivatethelighting.
NOTE:thearoundlightingsystemactivatesasthework-
inglightsareturnedon.
