5-TRANSPORTOPERATIONS
WARNING
Tip-overhazard!
Onlyraisethetrackaslittleasnecessary.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0276A
6.Positionthefrontequipmentasshowningure.
Makesurethatthebottomsideofthebucketpushes
onahardground.
7.Wraptwocables(2)aroundthearmtop.Makesure
tousepaddings(3)toavoiddamagestothearmand
tothecables.Foreachcable,connectoneendto
aratchetleverwinch,andtheotherendtotheother
ratchetleverwinch.
8.Slowlyextendthefrontequipmentsototensionall
thecables.
9.Usethefrontequipmentasalevertoslightlyraise
thetrackfromtheground.
10.Actuateratchetwinches(R)simultaneouslysoto
equallyextendedthefrontandtherearsectionof
thesideframe,untilthesideframeguidesreachthe
stoppersthatsettheextendedposition.
SMIL15CEXY209BB7
11.Slowlylowerthetracktotheground.
12.Makesurethattheretaininghardwareonthebase
frameoftheundercarriagematchesthexingholes
onthesideframe.
13.Installthe24xingboltstotheretaininghardware.
Thetighteningtorquemustbe1470–1920N·m
(1084.2–1416.1lbft).
14.Slowlyretractthefrontequipmentsotoloosenallthe
cables.Disconnecttheendsofthecables(C)and(2)
fromtheratchetleverwinches.Removethecables
(2)fromthearmtopandthecables(C)fromtheside
frame.
15.Repeatsteps2to14fortheothertrack.
16.Storethecablesandtheratchetleverwinches.
Themachineisnowreadyforeldoperation.
W79XCS-0018
5-8
