5-TRANSPORTOPERATIONS
Mainmodulesforroadtransport(CX500D)
SMIL19CEX2022GA2
Weight
(A)(B)(C)
Basemachine(LC)(1)35950kg(79256lb)3.55m(139.8in)10m(393.7in)2.75m(108.27in)
Basemachine(RTC)(1)37350kg(82343lb)3.70m(145.7in)9.98m(392.9in)(*)
Shortarm(2)2610kg(5754lb)1.33m(52.4in)3.83m(150.8in)0.85m(33.5in)
Counterweight(3)10200kg(22487lb)1.43m(56.3in)2.99m(117.7in)0.76m(29.9in)
NOTE:(*)Min2.39m(94.09in),Max2.89m(113.78in).
5-5
