4-OPERATINGINSTRUCTIONS

Emergencystopswitch

Theemergencystopswitchislocatedontheleft-hand

console.

Theemergencystopswitchenablestheenginetobeshut

downinemergencyorwhenitisnotpossibletoshutit

downbymeansofthestarterkey.

NOTICE:Theemergencystopswitchshouldbeusedfor

emergencypurposeonly.Donotuseitonaday-to-day

basistostoptheengine.

Pressonthefrontoftheswitchtostoptheengine.The

audiblewarningdevicesoundsandthemessageENGINE

STOPisdisplayed.

Tostarttheengineagain,pressonthebackoftheemer-

gencystopswitch,turnthestarterkeytoOFFposition,

andthenrestarttheengine

SMIL14CEX2520AA2

4-17
