4-OPERATINGINSTRUCTIONS
Straightlinetravel(forwardtravel)
Pressthetwopedals(orpushthetwolevers)forwardat
thesametime.
Alternativelypressthesingletravelpedalforward.
CS98M546ZA2
Straightlinetravel(reversetravel)
Pressthetwopedals(orpullthetwolevers)rearwardsat
thesametime.
Alternativelypressthesingletravelpedalbackward.
CS98M547TBP23
Turningtotheleft(forwardtravel)
Simplypresstheright-handpedalorpushtheright-hand
leverforwards.
SMIL13CEX2681AB4
Turningtotheright(forwardtravel)
Simplypresstheleft-handpedalorpushtheleft-hand
leverforwards.
SMIL13CEX2682AB5
4-19
