Case CX490D - Page 115

3-CONTROLSANDINSTRUMENTS
Leftmirror(A)
Themirrorshallbeinstalledasshowninthepicture.
Thedimension(L)is170mm(6.7in).
Thetighteningtorqueofthebolt(1)is71.6–91.2N·m
(52.8–67.3lbft).
SMIL14CEX2578AB3
Themirrorshallbepositionedsothatthesideontherear
leftofthemachineshallbevisible.
NOTICE:Afterinstallingandpositioningallthemirrors,
thevisibilityaroundthemachineshallbecheckedfromthe
operator'sseat.Settheseatintothedesiredposition,and
makesuretoconrmallthereferenceviewsinthemirrors.
Ifnecessary,netunethepositioningofthemirrorsin
ordertoensurepropervisibilityaroundthemachine.
SMIL14CEX2579AA4
3-63
