3-CONTROLSANDINSTRUMENTS
Stepsandaccesshandles
WARNING
Fallhazard!
Inordertoenterorexitthecab,theupperstructureframemustbeinlinewiththeundercarriage.
Failuretocomplycouldresultindeathorseriousinjury.
W0225A
WARNING
Fallhazard!
Cleanthestepsandaccesshandlestoremovealltracesofgrease,oil,mud,andice(inwinter).
Failuretocomplycouldresultindeathorseriousinjury.
W0139A
WARNING
Fallhazard!
Jumpingonoroffthemachinecouldcauseaninjury.Alwaysfacethemachine,usethehandrails
andsteps,andgetonoroffslowly.Maintainathree-pointcontacttoavoidfalling:bothhandsonthe
handrailsandonefootonthestep,oronehandonthehandrailandbothfeetonthesteps.
Failuretocomplycouldresultindeathorseriousinjury.
W0141A
Thesteps(1)allowtoaccessthemachinefromthe
ground.T ogetinoroutofthemachine,grabthehandles
(2),andusethesteps(1)andthetracks.
Thecatwalkplatforms(3)canbeoptionallyinstalled
alongsidetheupperstructure.
Thecatwalkplatformseasetheaccesstheoperator's
compartment,andallowtoreachtheservicecompart-
mentslocatedontheleftsideandontherightsideofthe
upperstructure.T omovealongthecatwalkplatforms,
makesuretograbthehandles(4).
NOTICE:neverusetheleftconsole,theleft-handcontrol
leverorthegatelockleverinplaceofthehandleswhen
gettingonorofftheoperator’scompartment.
SMIL15CEXY147AB4
SMIL15CEXY148AB5
