3-CONTROLSANDINSTRUMENTS
FollowthestepsbelowtoaddDEF/AdBlue®:
1.TurnthestarterkeytoOFFposition.Wait3minforSCRsystemtocompletelysuckDEF/AdBlue®backintothe
tank.
2.Turnthekeycylinder(2)withthestarterkeytounlocktheDEF/AdBlue®tankcover(1).Turnthecoveraccess
handle(3)anddrawopenthecover(1)frontward.
3.WipetheinletontheDEF/AdBlue®tank(4)cleanofdirt,mud,andforeignobjects.
NOTICE:somewhitepowderdepositsmayformwhenDEF/AdBlue®adheresanddriesinplacessuchasthe
supplyinlet.WipeoffthesedepositstopreventthemfromenteringtheDEF/AdBlue®tank.
4.Turnthecap(6)counterclockwiseandopenthellerneck.
NOTICE:DEF/AdBlue®mayemitanodorwhenthetankcapisopened.Donotattempttosmellinsidethetank
fromthesupplyinlet.
5.RelluptotheF(upperlimit)mark(7)onthelevelgauge(5).
NOTICE:neverrellDEF/AdBlue®overtheF(upperlimit)markonthelevelgauge.Adequateairvolumemust
bepresentinthetopofthetankforproperfunctionalityoftheSCRsystem.Moreover,DEF/AdBlue®mayleaks
fromthebreatherhoseduringuse,andsensorsmaybedamagedwhenitbecomesfrozen.
NOTICE:ifDEF/AdBlue®spillswhileadding,wipeoffthespillagewithaclothandthenrinsetheareawithfresh
water.DEF/AdBlue®willcausecorrosiononpaintedandunpaintedmetallicsurfaces,andmaydistortsome
plasticandrubbercomponents.
6.Putthecap(6)onthellerneck.Turnthecapclockwisetoclosethellerneck.
SMIL19CEX0571EB4
1.DEF/AdBlue®tankcover
2.Keycylinder
3.Coveraccesshandle
4.DEF/AdBlue®tank
5.Levelgauge
6.Tankcap
7.UpperlimitlevelofDEF/AdBlue®toberelled.
