Themachinecontrolsystemprovidesspeciccombinationsofvisualandacousticsignalsinordertomaketheoper-
atorawareofthestartingandtheprogressingofaninducementsequence.
InducementsequenceforrellingDEF/AdBlue®
Rearcameraviewoperatingmode.
SMIL19CEX2012AA14
(A)LevelofDEF/AdBlue®around10%oftankcapacity.
DEF/AdBlue®gaugewhite.
(B)LevelofDEF/AdBlue®below10%oftankcapacity.
DEF/AdBlue®gaugeorange.
DEF/AdBlue®rellwarningdisplayed.
displayed.
Onelongbeep.
(C)LevelofDEF/AdBlue®below5%oftankcapacity.
DEF/AdBlue®gaugeorangeandashing.
DEF/AdBlue®rellwarningslowashing.
displayed.
Threeshortbeeps.
(D)DEF/AdBlue®tankempty
DEF/AdBlue®gaugered.
DEF/AdBlue®rellwarningfastashing.
displayed.
Continuousbeep.
Atthestep(D),theoperationofthemachineshallbe
stopped.Reachasafeconditionforthemachine,and
immediatelyrellDEF/AdBlue®intothetankaccording
totheproceduredescribedinthenextpage.
