InducementsequenceforreplacingDEF/AdBlue®,orforrepairingtheSCRsystem.
Rearcameraviewoperatingmode.
SMIL19CEX2012AA18
(A)Normaloperation.
(B)DEF/AdBlue®badquality,orSCRproblem.
SCRwarningsignsdisplayed.
displayed.
Onelongbeep.
(C)After3hwithnoactiontaken.
SCRdetectioniconslowashing.
displayed.
Threeshortbeeps.
(D)After30minwithnoactiontaken.
SCRdetectioniconfastashing.
displayed.
Continuousbeep.
Atthestep(D),theoperationofthemachineshallbe
stopped.Reachasafeconditionforthemachine,and
immediatelycalltheCASECONSTRUCTIONdealerfor
inspectionandrepairoftheSCRsystem,andforreplace-
mentoftheuidintotheDEF/AdBlue®tankwiththe
properone.
