4-OPERATINGINSTRUCTIONS

Diggingandloadingoperations

UsetheHworkmodeforgeneraldiggingandtruckloadingoperations.

UsetheSPworkmodeforheavydiggingoperation.

Filling

Fillthebucketbymanoeuvringthearm.

Keepthebottomofthebucketparalleltothecut.

Thebucketteethandblademustcutthegroundlikethebladeofaknife.

Thedepthofdigvariesdependingonthetypeofmaterial.

Excavatingmethod

SMIL13CEX2693EA2

SMIL13CEX2694EB3

1.Correct

2.Incorrect.Thebucketwilldiginandcauseastall.

3.Incorrect.Thebucketispushedupwards.Thiswillalsoincreasethecycletime.

4-9
