5-TRANSPORTOPERATIONS
Machinesetup
Accuratelycleanthemachineundercarriageandtracksto
preventmudordebrisfromskiddingduringtransport.
Getonthemachineandstarttheengine.
Makesuretodeactivatetheautoidlefunctionandtheauto
shut-downfunction.Presstheidlemodebutton(1)until
anyidleicononthedisplayturnsoff.
Pressthetravelmodeselectorbutton(2)toselectthelow
travelspeed.The“Turtle”iconappearsonthedisplay.
SelecttheHworkmodeandsetthegatelockleverin
forwardposition.
SMIL14CEX2560AB2
Raisetheboomsoasnottointerferewiththetrailerbed.
Aligntheupperframetotheundercarriagesoasthecab
isovertheidlerwheels.
Getthemachineclosetothetrailer:theidlerwheels
shouldfacethetrailerramps,andtheundercarriage
shouldbecenteredrespecttothetrailer.
Slowlyclimbthetrailerramps.
SMIL19CEX2028AA3
Slowlytravelonthetrailerbedtoreachtherestingposi-
tion.
Lowertheboomtothetrailerbed.
SMIL19CEX2027AA4
