5-TRANSPORTOPERATIONS
Mainmodulesforshippingtransport(CX500D)
SMIL19CEX2024GA2
Weight
(A)(B)(C)
Basemachine(LC)(1)30200kg(66580lb)3.55m(139.8in)6.24m(245.7in)2.75m(108.27in)
Basemachine(RTC)(1)31600kg(69666lb)3.70m(145.7in)6.24m(245.7in)(*)
Shortarm(2)2610kg(5754lb)1.33m(52.4in)3.83m(150.8in)0.85m(33.5in)
Counterweight(3)10200kg(22487lb)1.43m(56.3in)2.99m(117.7in)0.76m(29.9in)
Boom(4)4850kg(10692lb)1.92m(75.6in)6.82m(268.5in)0.95m(37.4in)
Boomcylinders(5)890kg(1962lb)0.97m(38.2in)2.44m(96.1in)0.65m(25.6in)
NOTE:(*)Min2.39m(94.09in),Max2.89m(113.78in).
