6-MAINTENANCE

7.Checkthatthedustejectorunderthelterisoperating

correctly.

NOTE:If,aftercleaning,smokeexhaustisabnormal,be

suretoreplacetheprimaryelementoftheaircleaner.

SMIL18CEX0439AA7

Pre-cleaner

Unlockthepre-cleanercover,andremovethe

pre-cleanercup.Getdownfromthemachine,and

dischargedustanddebrisaccumulatedintothecup.

Cleanthepre-cleanercup.

Installthepre-cleanercup,andlockthepre-cleaner

cover.

SMIL18CEX0442AA8

6-29
