6-MAINTENANCE

Boomcylinderbottompin:twogreasettings.

SMIL15CEXY534AB3

Boom/armlinkage:onegreasettingoneachsideof

thearm.

SMIL15CEXY535AB4

Armcylindertoppin:onegreasetting.

SMIL15CEXY536AB5

Armlink/Connectingrod:fourgreasettings.

NOTICE:thearmlinkandtheconnectingrodshallbelu-

bricatedevery10hifanyattachmentotherthanabucket

isused.

SMIL15CEXY537AB6

6-48
