6-MAINTENANCE

5.Pulltheclipoutwardandremovethelightbulb.In-

stallanewlightbulbofthesamewattage(70W).

6.Installtheclip,puttheheadlightbackinpositionand

installthescrewsandtheplug.

7.Installtheswitchbracket.

NOTICE:neverputyourngersonatungsteniodidebulb.

SMIL13CEX2835AB9

6-80
