8-SPECIFICATIONS
Arm
2.53m
(99.61in)
3.38m
(133.07in)
4.00m
(157.48in)
4.85m
(190.94in)
(A)Maxdiggingreach
11.23m
(442.13in)
11.99m
(472.05in)
12.52m
(492.91in)
13.27m
(522.44in)
(B)Maxdiggingreachatgroundlevel(GL)
10.99m
(432.68in)
11.76m
(462.99in)
12.30m
(484.25in)
13.06m
(514.17in)
(C)Maxdiggingdepth
6.88m
(270.87in)
7.74m
(304.72in)
8.34m
(328.35in)
9.20m
(362.20in)
(D)Maxdumpheight
7.40m
(291.34in)
7.68m
(302.36in)
7.87m
(309.84in)
8.07m
(317.72in)
(E)Maxdumpdistance
8.07m
(317.72in)
8.88m
(349.61in)
9.46m
(372.44in)
10.29m
(405.12in)
(F)Maxworkingheight
10.86m
(427.56in)
11.10m
(437.01in)
11.26m
(443.31in)
11.46m
(451.18in)
(G)Reachatmaxworkingheight
7.14m
(281.10in)
8.00m
(314.96in)
8.62m
(339.37in)
9.46m
(372.44in)
(H)Minequipmentswingradius
4.93m
(194.09in)
4.97m
(195.67in)
4.91m
(193.31in)
5.09m
(200.39in)
(I)Heightatminequipmentswingradius
9.33m
(367.32in)
9.30m
(366.14in)
9.27m
(364.96in)
9.34m
(367.72in)
(L)Mincleanupdistance
4.08m
(160.63in)
3.31m
(130.31in)
2.65m
(104.33in)
2.45m
(96.46in)
(M)Maxcleanupdistance
8.31m
(327.17in)
8.98m
(353.54in)
9.49m
(373.62in)
10.23m
(402.76in)
(N)Maxdiggingdepthonaverticalface
5.99m
(235.83in)
6.64m
(261.42in)
7.12m
(280.31in)
7.96m
(313.39in)
(O)Reachatmaxdiggingdepthonaverticalface
7.45m
(293.31in)
7.84m
(308.66in)
8.11m
(319.29in)
8.25m
(324.80in)
(P)Maxat-bottomedtrenchingdepth
6.70m
(263.78in)
7.59m
(298.82in)
8.21m
(323.23in)
9.08m
(357.48in)
(Q)Distanceofat-bottomedtrench
4.00m
(157.48in)
4.00m
(157.48in)
4.00m
(157.48in)
4.00m
(157.48in)
(R)Flat-bottomedtrenchreferencelenght2.44m(96.06in)
(S)Swingtailradius3.73m(146.85in)
NOTE:thedimensionsoftheworkingrangearedenedbasingonthetworeferencelines(GL)(groundlevel)and
(CL)(centerline,i.e.rotationaxisofthemachine).Allthedimensionsrelatedtothe(GL)aredenedwiththegrousers
indentedintotheground.
NOTICE:the2.53m(99.61in)armisasuper-shorttypearmwhichismainlyintendedtomaximizetheexcavating
performance.Withthe2.53m(99.61in)arm,thebucketcannotbefullycurledafterthearmhasbeenfullyretracted.
Respectively,thearmcannotbefullyretractedafterthebuckethasbeenfullycurled.Thereferencedimension(H)is
denedwiththearmfullyclosedandthebucketnotfullycurled.
8-11
