Case CX490D - Page 301

8-SPECIFICATIONS
Arm
2.53m
(99.61in)
3.38m
(133.07in)
4.00m
(157.48in)
4.85m
(190.94in)
(A)Maxdiggingreach
11.23m
(442.13in)
11.99m
(472.05in)
12.52m
(492.91in)
13.27m
(522.44in)
(B)Maxdiggingreachatgroundlevel(GL)
10.96m
(431.50in)
11.73m
(461.81in)
12.27m
(483.07in)
13.03m
(512.99in)
(C)Maxdiggingdepth
6.73m
(264.96in)
7.58m
(298.43in)
8.19m
(322.44in)
9.05m
(356.30in)
(D)Maxdumpheight
7.55m
(297.24in)
7.83m
(308.27in)
8.02m
(315.75in)
8.22m
(323.62in)
(E)Maxdumpdistance
8.07m
(317.72in)
8.88m
(349.61in)
9.46m
(372.44in)
10.29m
(405.12in)
(F)Maxworkingheight
11.01m
(433.46in)
11.25m
(442.91in)
11.41m
(449.21in)
11.61m
(457.09in)
(G)Reachatmaxworkingheight
7.14m
(281.10in)
8.00m
(314.96in)
8.62m
(339.37in)
9.46m
(372.44in)
(H)Minequipmentswingradius
4.93m
(194.09in)
4.97m
(195.67in)
4.91m
(193.31in)
5.09m
(200.39in)
(I)Heightatminequipmentswingradius
9.48m
(373.23in)
9.45m
(372.05in)
9.42m
(370.87in)
9.49m
(373.62in)
(L)Mincleanupdistance
4.05m
(159.45in)
3.28m
(129.13in)
2.62m
(103.15in)
2.40m
(94.49in)
(M)Maxcleanupdistance
8.28m
(325.98in)
8.96m
(352.76in)
9.48m
(373.23in)
10.22m
(402.36in)
(N)Maxdiggingdepthonaverticalface
5.84m
(229.92in)
6.49m
(255.51in)
6.97m
(274.41in)
7.81m
(307.48in)
(O)Reachatmaxdiggingdepthonaverticalface
7.45m
(293.31in)
7.84m
(308.66in)
8.11m
(319.29in)
8.25m
(324.80in)
(P)Maxat-bottomedtrenchingdepth
6.55m
(257.87in)
7.44m
(292.91in)
8.06m
(317.32in)
8.93m
(351.57in)
(Q)Distanceofat-bottomedtrench
4.00m
(157.48in)
4.00m
(157.48in)
4.00m
(157.48in)
4.00m
(157.48in)
(R)Flat-bottomedtrenchreferencelenght2.44m(96.06in)
(S)Swingtailradius3.73m(146.85in)
NOTE:thedimensionsoftheworkingrangearedenedbasingonthetworeferencelines(GL)(groundlevel)and
(CL)(centerline,i.e.rotationaxisofthemachine).Allthedimensionsrelatedtothe(GL)aredenedwiththegrousers
indentedintotheground.
NOTICE:the2.53m(99.61in)armisasuper-shorttypearmwhichismainlyintendedtomaximizetheexcavating
performance.Withthe2.53m(99.61in)arm,thebucketcannotbefullycurledafterthearmhasbeenfullyretracted.
Respectively,thearmcannotbefullyretractedafterthebuckethasbeenfullycurled.Thereferencedimension(H)is
denedwiththearmfullyclosedandthebucketnotfullycurled.
8-13
