8-SPECIFICATIONS
Arm
2.53m(99.61in)
(A)Maxdiggingreach10.87m(427.95in)
(B)Maxdiggingreachatgroundlevel(GL)10.59m(416.93in)
(C)Maxdiggingdepth6.41m(252.36in)
(D)Maxdumpheight7.24m(285.04in)
(E)Maxdumpdistance7.78m(306.30in)
(F)Maxworkingheight10.73m(422.44in)
(G)Reachatmaxworkingheight6.94m(273.23in)
(H)Minequipmentswingradius4.59m(180.71in)
(I)Heightatminequipmentswingradius9.20m(362.20in)
(L)Mincleanupdistance3.80m(149.61in)
(M)Maxcleanupdistance7.85m(309.06in)
(N)Maxdiggingdepthonaverticalface3.26m(128.35in)
(O)Reachatmaxdiggingdepthonaverticalface9.23m(363.39in)
(P)Maxat-bottomedtrenchingdepth6.24m(245.67in)
(Q)Distanceofat-bottomedtrench3.77m(148.43in)
(R)Flat-bottomedtrenchreferencelenght2.44m(96.06in)
(S)Swingtailradius3.73m(146.85in)
NOTE:thedimensionsoftheworkingrangearedenedbasingonthetworeferencelines(GL)(groundlevel)and
(CL)(centerline,i.e.rotationaxisofthemachine).Allthedimensionsrelatedtothe(GL)aredenedwiththegrousers
indentedintotheground.
NOTICE:the2.53m(99.61in)armisasuper-shorttypearmwhichismainlyintendedtomaximizetheexcavating
performance.Withthe2.53m(99.61in)arm,thebucketcannotbefullycurledafterthearmhasbeenfullyretracted.
Respectively,thearmcannotbefullyretractedafterthebuckethasbeenfullycurled.Thereferencedimension(H)is
denedwiththearmfullyclosedandthebucketnotfullycurled.
8-17
