9-ACCESSORIES
Directtbucketsapplication(CX500DLC)
HeavyDutybuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
2.53m(99.61in)
2.33m³(3.05yd³)1370mm(54in)2540kg(5600lb)
○
2.63m³(3.44yd³)1525mm(60in)2720kg(5997lb)
סּ
2.92m³(3.82yd³)1675mm(66in)2900kg(6393lb)
●
SevereDutybuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
2.53m(99.61in)
2.33m³(3.05yd³)1370mm(54in)3030kg(6680lb)
○
2.63m³(3.44yd³)1525mm(60in)3250kg(7165lb)
●
○Densityofmaterialupto2t/m
3
סּDensityofmaterialupto1.8t/m
3
●Densityofmaterialupto1.6t/m
3
NOTICE:Foroperationinquarry,themachinemustbeequippedwith750mm(30in)tracks,andintegraltrackguards.
9-4
