2-SAFETYINFORMATION
UsinganImplementotherthanabucket
•
Whenusingaspecialimplement(hydraulicbreaker,
cuttercrusheretc.),refertotheoperator'smanualpro-
videdwiththeimplement.
Implementoperationandmaintenance
•
Fortheimplementoperationandmaintenance,referto
theoperator'smanualprovidedwiththeimplement.
Safetyarea
Thesafetyareaisthespacenecessaryforthemachineto
operateatthemaximumrangeofthetoolandatfullswing
360°plus2m(6.56ft).
(1)Workingarea.
(2)Safetyarea.
SMIL13CEX2517AB1
2-10
