Operatingcontrols
Usetheproportionalswitchlocatedontheleft-handcon-
trollevertooperatethegrabrotationorthebuckettiltwith
avariablepower.
Makesurethatthecontrolpatternofthepositioningactu-
ationisasintended.Slideupanddowntheproportional
switchandconrmthecontroldirections(e.g.left/right).
NOTICE:Ifcontroldirectionsforthepositioningactuation
arenotasintended,checkforanalternativesetupofthe
hydraulicconnectionsbetweentheattachmentandthe
machine.
NOTICE:Alwayskeepeachconnectinghoseonthesame
sideofthearm.Nevercross-overtheconnectinghoses
betweenthetwosidesofthearm.
NOTICE:Ifnotusinganyhydraulicattachment,donot
operatecontrolsforauxiliaryhydrauliccircuits.
