9-ACCESSORIES

Stopworkingifhydraulichoseslookabnormallybent.

ContactyourauthorizedDealer.

NH019724

Donotoperatethehydraulicbreakerinwater.Doingso

willcauserustandsealdamage,resultingindamageto

thehydraulicsystemcomponents.

NH019925

Donotusethehydraulicbreakertomoveobjects.Theex-

cavatormightoverturnand/orthehydraulicbreakermay

bedamaged.

NH020026

Donotoperatethebreakertothesideofthemachine.

Themachinemaybecomeunstableandundercarriage

componentslifemaybereduced.

NH020127

9-22
