9-ACCESSORIES
CASECONSTRUCTIONquickcoupler(CX500D)
CASECONSTRUCTIONcanprovideahydraulicquickcouplerandadedicatedrangeofCouplerbuckets.
TheCASECONSTRUCTIONCouplerbucketsaredesignedtooptimizethettingtotheCASECONSTRUCTION
quickcoupler,andaredesignedtooptimizetheoperatingperformanceoftheCASECONSTRUCTIONexcavatorsin
mostofconstructionworks.
SMIL15CEX3064EA2
Maindimensions
(E)481mm(18.9in)
(G)625mm(24.6in)
(H)775mm(30.5in)
Weight
900kg(1984lb)
NOTICE:usageofbucketsotherthanCASECONSTRUCTIONCouplerbucketsisstrictlylimitedtotheconditionthat
thebuckethangersmatchwiththedimensionsindicatedinthetablebelow.ContactyourCASECONSTRUCTION
dealerforcheckingthebucketsintendedforusage.
Bucketttingdimensions
Bucketpindiameter
100mm(3.9in)110mm(4.3in)
Minimumpinspread(A)537mm(21.1in)542mm(21.3in)
Maximumpinspread(B)630mm(24.8in)635mm(25.0in)
Seatingwidth(F)440mm(17.3in)
Quickcoupleridenticationplate
TheidenticationplateoftheCASECONSTRUCTIONquickcouplerislocatedontheinsideofthetophangers.
Serialnumber:
Weight:
Workingpressure:
Type/Model:
Partnumber:
Yearofmanufacture:
SWL(SafeWorkingLoad):
9-35
