9-ACCESSORIES

Maintenance

Greasethequickcouplerlinkageevery50h.

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE.

Setthequickcouplercylinderinretractedposition.Put

greaseintothegreasepointsshowningure.

•

Cylinderbottompin:onelubricationpoint.

Lockingbarpivot:onelubricationpoint.

Latchingsystempivot:onelubricationpoint.

SMIL14CEX2734AA4

•

Hookpivot:onelubricationpoint.

SMIL14CEX2736AA5

•

Cylindertoppin:onelubricationpoint.

SMIL14CEX2735AA6

NOTICE:thecouplerlinkageshallbelubricatedevery

10hifthemachineisoperatedinwaterormud.

9-38
