2-SAFETYINFORMATION
(1F)Parkingthemachine
Beforeleavingtheoperator'scompartment,alwayslower
thebuckettotheground,placethegatelockleverin
lockedposition,stoptheengineandremovethestarter
keyinordertopreventanyunintendedmovementofthe
machine.
KHP36590_F9
(2)Functionsofoperationlevers
Partnumber:KHP27000
Functionsoftheleftcontrolleverandtherightcontrol
lever.
Alwaysmakesuretoplacethesheetthatmapstheop-
eratingcontrolstothesidecorrespondingtotheselected
controlpattern.
KHP2700010
(3)Windshieldlocking
Partnumber:KHP35800
Alwayslockthewindshieldwhenitissetinopenposition.
Windshieldnotlockedmayfalldownandcanaffectsafe
andproperoperationofthemachine,andcanevencause
injuries.
KHP3580011
(4)Loadshandlingchart
Partnumber:KTP13370(CX490D)
Partnumber:KTP13480(CX500D)
Alwaysmakesuretoliftloadsnotexceedingthemaxi-
mumvaluesprescribedbytheloadshandlingchart.
KTP1337012
