3-CONTROLSANDINSTRUMENTS
Thesingletravelpedalallowstomovethemachinestraightforwardorstraightbackward.
NOTE:Thesingletravelpedalshallnotbeusedtogetherwiththetravelcontrolleversandpedals.Thesingletravel
pedalfunctionisalternativetothe(a)+(b)functionandthe(c)+(d)functionobtainablewiththetravelcontrolpedals
andlevers.
NOTICE:alwayslockthesingletravelpedalwhennotinuse.
Lockingthesingletravelpedal
Tolockthesingletravelpedal,engagethelockingpin(1)
inthelockinghole(2).
SNKQ6K-003A14
Tousethepedal,placethelockingpin(1)inoutwardpo-
sition.
SMIL14CEX1681AB15
NOTE:ifthelockingpin(1)isinposition(3),onlythe
forwardtravelispossible
SNKQ6K-002A16
3-11
