CESAB S210 User Manual

© Cesab 8 – 39 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
8:029
Charged capacity
exceeds battery
capacity.
Not influenced
1: Battery
parameters
109 and 110
incorrectly set.
2: The battery is
defective
1: Check parameters
• Check that factory parameters
are set according to the truck
configuration.
• Check that other parameters
are set correctly.
2: Check the battery.
8:030
Communication
with charger T14
exists, but factory
parameter 1101 is
not activated.
Not influenced
1: Incorrect value
for parameter
1101
1: Check parameters
• Check that factory parameters
are set according to the truck
configuration.
• Check that other parameters
are set correctly.
8:031
Saving parameter
in T14 failed.
Not influenced
1: No software
compatibility
1: Update the truck software
• Update the truck software to the
latest version.
8:032
Wrong battery type
selected via
parameters 109
and 110.
Not influenced
1: Battery
parameters
109 and 110
incorrectly set.
1: Check parameters
• Check that factory parameters
are set according to the truck
configuration.
• Check that other parameters
are set correctly.
8:033
CAN
communication
problems between
BMS and BCU
(A30)
Creep speed,
blocked lifting/
lowering
movement
1: Error on CAN
bus wiring or
connections
1: Check the CAN bus
• Check that CAN bus is intact in
terms of wiring harness,
resistance and connectors.
Disconnect the battery. Check
that the resistance between
(X41:3) and (X41:4) is 54 - 66
ohms.
• Check that the CAN wiring
harness is not pinched.
Measure resistance between
the chassis and CAN connector.
Limit value >24 kOhm
Code Description
Truck
behaviour
Error cause(s) Procedure
