CESAB S210 - 24.2 S212 L, S214 L, S220 D

To Next Page

To Previous Page

T Code(s):

841, 842, 843

Repair manual:

Technical data

Model(s):

S210, S212, S212S, S212L, S214, S214L, S220D

Publication Number:

7588857-040

Date:

2018-05-01

Applies from serial number:

6384351-

24.2 S212L, S214L, S220D

Model S212L S214L S220D

Drive motor

Type Iskra AML7109

Power, kW 1.5

Duty cycle S2-60 min

Weight, kg 10.5

Brake

Type Warner PK10

Braking force, Nm 15

Power, W 51/13

Resistance, coil, Ω 10.5-12.0

Nominal gap in actuated position,

0.2-0.55

Minimum thickness of brake disc,

7.9

Thickness of new brake disc, mm 8.2

Transmission/gear mechanism

Type Kordel Genius 5.72.02.1

Gear ratio 30.204

Oil volume, litres 0.8

Oil See section “23.2 Lubricants specification”.
